Electromechanical Hour Meter, 110-127 VAC, 60 Hz, Panel mount - HM SFT-48 161
Model#051510311
Electromechanical Hour Meter, 110-127 VAC, 60 Hz, Panel mount - HM SFT-48 161
Model#051510311
- Monitors up to 99,999.99 hours of operation
- Flush mounting
- IP20 protection rating
- 99,999 hours of equipment monitoring.
- Distribution/Control Panel
- Distribution Panel
- Machinery & Pump Controls
- Monitoring
- Septic Treatment
Color White/grey Input Voltage Range(s) 110-127 VAC Mounting Options Flush, Installation Input Voltage Frequencies 60 Hz Mechanical Movement Synchronous Wiring Option Flat connection DIN 6.3 Housing Material Plastic Accuracy Mains synchronized Housing type Flush Mounting Warranty Period 1-Year limited CAProp65Message This product is in compliance with Prop65 Country Of Origin Mexico Digits Coloring (Hours) White on Black Digits Coloring (Tenths) White on Black Environmental Rating IP20 Hour Meter Material Plastic Meter display Analogue (7 digits), Hours Power consumption (Standby) 1 VA Protection class II, According to Corresponding Mounting Protection type IP20, IP54 with Sealing RoHS Certification Y Auto Start/Stop False Check Valve False DOE Compliant False Freeze protection False Leaf Screen False Operating Temperature Max (°C) 55 Operating Temperature Max (°F) 131 Operating Temperature Min (°C) -20 Operating Temperature Min (°F) -4 Product Depth (in) 1.574 Product Depth (mm) 40 Product Height (in) 2.165 Product Height (mm) 55 Product Width (in) 1.889 Product Width (mm) 48 Self Priming False Submersible False UL Certification UL Unit Carton Height (in) 1 Unit Carton Length (in) 1 Unit Carton Weight (lb) 1 Unit Carton Width (in) 1 Units Per Pallet 999 UV Resiliant Outdoor Enclosure False
